High Clearance Aluminum Solar Structure for Large Scale Solar Farm Projects Agri PV Complementary Mounting System

Name: High Clearance Aluminum Solar Structure for Large Scale Solar Farm Projects Agri PV Complementary Mounting System
Brand: JJ PV SOLAR LIMITED
Price: 100.0 USD
Availability: InStock

Price 100.0 USD ($)/ Unit

Get a Price/Quote

MOQ : 600 Units

High Clearance Aluminum Solar Structure for Large Scale Solar Farm Projects Agri PV Complementary Mounting System Specification

Maintenance Type
Low maintenance; periodic inspection recommended

Features
High ground clearance for agricultural machinery, corrosion-resistant, modular design, customizable for different terrains, pre-assembled components, easy installation

Efficiency
N/A (Structure only)

Product Type
High Clearance Aluminum Solar Structure

Material
Anodized Aluminum Alloy (AL6005-T5), Stainless Steel (SUS304) Fasteners

Power
N/A (Structure only, does not generate power)

Operating Temperature
-40C to +85C

Output Voltage
N/A (Mounting structure only)

Size
Customizable span and height per project requirement

Dimension (L*W*H)
Customizable, typical clearance height 2.5m - 4.5m

Color
Silver (Natural Anodized)

Weight
Depends on layout, typically 40-55 kg per set

Application
Large Scale Solar Farm, Agri-PV Integration, Agricultural Land Use

Type Of Technology
Agri PV Complementary Mounting System

Installation Type
Ground Mounted, High Clearance

Foundation Type
Concrete, Pre-cast, or Ground Screws

Wind Load Resistance
Up to 60 m/s (customizable based on site requirements)

PV Module Compatibility
Mono/Poly/Thin Film panels, up to 210mm wide cell module

Snow Load Resistance
Up to 1.4kN/m2 (customizable)

Max Row Length
Up to 72 meters without expansion joint (depends on site)

Corrosion Protection
Anodized layer 12m

Ground Clearance
Typically 2.5-4.5 meters (adjustable for agricultural operations)

Assembly Method
Bolted connections, no welding required

Panel Orientation
Portrait or Landscape

Design Life
25 years+

High Clearance Aluminum Solar Structure for Large Scale Solar Farm Projects Agri PV Complementary Mounting System Trade Information

Minimum Order Quantity
600 Units

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

About High Clearance Aluminum Solar Structure for Large Scale Solar Farm Projects Agri PV Complementary Mounting System

Jump on this extraordinary opportunity to secure a High Clearance Aluminum Solar Structure, meticulously designed for valorous performance in large-scale solar farm and Agri PV complementary projects. Get exceptional adaptation with a customizable ground clearance (2.5-4.5 meters), suiting both solar output and agricultural operations. This exquisite mounting system, crafted from anodized AL6005-T5 aluminum and SUS304 fasteners, offers robust wind (up to 60 m/s) and snow resistance (up to 1.4kN/m2). Enjoy low maintenance, corrosion protection, and the flexibility to use portrait/landscape orientations for a diverse range of module types, all while simplifying installation with bolted connections. Offer your solar farm unyielding stability and enduring service life with this modular masterpiece.

Agri PV Mounting System-Versatility for Solar Farms and Agriculture

This high-clearance aluminum solar structure brings an exquisite synergy between agriculture and solar energy. Its valorous ground clearance (2.5-4.5 meters) is tailormade for accommodating agricultural machinery while simultaneously securing robust PV support. Developed specifically for large-scale farms, it caters to varied terrains and module types, offering customizable spans and orientations. Easy installation, modularity, and a low-maintenance design add to its extraordinary utility, making it the ideal choice for integrating solar power with ongoing agricultural operations.

Sample Policy, Logistics & Export Market Support

Sample availability is offered to buyers to ensure complete satisfaction before finalizing large orders. FOB port options are easily arranged across major Indian ports, streamlining logistics and shipment to address the needs of global export markets. Delivery times are tailored to project scale, typically ranging from 2-6 weeks post-order confirmation. Rely on the seamless coordination between production and export logistics, designed for timely and secure shipments of these premium solar mounting solutions.

FAQ's of High Clearance Aluminum Solar Structure for Large Scale Solar Farm Projects Agri PV Complementary Mounting System:

Q: How does the solar structure support agricultural activities?

A: The high ground clearance and modular design allow agricultural machinery to operate efficiently beneath the mounted PV systems, optimizing land use for both farming and energy production.

Q: What types of PV modules are compatible with this mounting system?

A: This structure is compatible with mono, poly, and thin film panels up to 210mm wide cell modules, supporting both portrait and landscape orientations.

Q: When can one expect delivery after placing an order?

A: Typical delivery times range from 2 to 6 weeks post-order confirmation, depending on the project scope and customization requirements.

Q: Where can the mounting structure be installed?

A: It is suitable for large-scale solar farms, agricultural lands, and Agri-PV integration projects on various terrains, as the foundation options include concrete, precast, or ground screws.

Q: What is the process for assembling this structure?

A: The system uses bolted connections for assembly, requiring no welding. Pre-assembled components make the installation process efficient and straightforward.

Q: What are the benefits of choosing this mounting system for export markets?

A: Buyers benefit from customizable configurations, high durability, easy logistics through major ports, and a dedicated export support team for smooth international transactions.
